GEARBOX FOR INDUSTRIALS

Gear box standard form

As a standardized power-transmission reduction gear, this was developed on the basis of the newest design and analysis technique. This precise and reliable product widely used in industrial settings is used to transmit power in diverse facilities such as steelwork, power plant, chemical plant, cement, rubber and paper manufacturing plants.

Parallel Shaft
As the parallel shaft reduction gear uses HELICAL GEAR, the input shaft and output shaft point to parallel directions. This is the most frequently used from of reduction gear in the industrial settings and can satisfy various requirements of customers.
Power	1 ~ 5,000 kW
Reduction gear ratio	1 Stage (1~1/6.3), 2 Stage (1/6.3~1/22.4), 3 Stage (1/22.4~1/100), 4 Stage (1/112~1/500)
Torque	74,400 kg-m
